SUPER FINE FILTER EU-7 (F-7) |
 |
SUITABLE FOR
- Air Filtration of 1μ to 3μ particles.
- Secondary filtration in clean room industry such Electronics,
Pharmaceuticals, Medical devices, paint booths etc.
- Final filtration in Food & Dairy Industry, Mechanical precision assemblies,
O.T.'S Hospitals, Smoking Areas, & Hotels. etc.
Supercut filters are manufactured & tested in state of art machinery and
testing facilities.
|
 |
CONSTRUCTION & STANDARD
| Filter Media |
: |
Non Woven Synthetic Deep Pleated/Panel / Pocket Type |
| Media Support |
: |
Aluminium/GI/HDPE Mesh |
| Frame Material |
: |
Aluminium / MS/ SS / GI |
| Frame Type |
: |
Box / Flange |
| Max. Op. Temp. |
: |
80ºC |
| Sealant |
: |
Epoxy Resin |
| Gasket |
: |
None (Box type & Pocket
type) Syn Rubber / PE Foam
(Flange / Panel) / Food Grade |
| Direction of Air Flow |
: |
Flange to Cassette or reverse |
| Note :- MERV rated filters as per ASHRAE 52.2 available |
|
SUPER FINE FILTER EU-8 (F-8) |
 |
SUITABLE FOR
- Air Filtration of 0.3μ to 1μ particles.
- Secondary filtration in clean room industry such as Electronics, Pharmaceuticals, Medical devices , Vaccine, Production Work, Injection Filling Work, Photo film & Many others.
- Final Filtration in Minor O.T.S Hospitals
& Smoking Areas.
Supercut filters are manufactured & tested in state of art machinery and
testing facilities.
|
 |
CONSTRUCTION & STANDARD
| Filter Media |
: |
Non Woven Synthetic
Deep Pleated/Panel /
Pocket Type |
| Media Support |
: |
Aluminium/GI/HDPE Mesh |
| Frame Material |
: |
Aluminium / MS/ SS |
| Frame Type |
: |
Box / Flange |
| Max. Op. Temp. |
: |
80ºC |
| Sealant |
: |
Epoxy Resin |
| Gasket |
: |
None (Box type & Pocket
type) Syn Rubber / PE Foam / Food Grade
(Flange / Panel) |
| Direction of Air Flow |
: |
Flange to Cassette or reverse |
| Note :- MERV rated filters as per ASHRAE 52.2 available |
|
SUPER FINE FILTER (Semi Hepa) EU-9 (H-9) |
|
SUITABLE FOR
- Air Filtration of 0.3μ to 1μ particles.
- Secondary filtration in clean room industry such as Electronics,
Pharmaceuticals, Medical devices, Photo Film & many others.
- Final filtration in Food & Dairy Industry, Mechanical precision assemblies,
O.T.'S Hospitals, Smoking Areas, & Hotels. etc.
Supercut filters are manufactured & tested in state of art machinery and
testing facilities.
|
 |
CONSTRUCTION & STANDARD
| Filter Media |
: |
Micro Fibre Glass
Paper Deep Pleated |
| Media Support |
: |
Aluminium Foil/Hot Melt |
| Frame Material |
: |
Aluminium / GI |
| Frame Type |
: |
Box / Flange |
| Max. Op. Temp. |
: |
80ºC |
| Sealant |
: |
Epoxy Resin |
| Gasket |
: |
Syn Rubber / Food Grade / Neoprene Rubber |
|
